Concrete cutter
PCC500-1Professional Type: PCC500-1
With the more professional design and more stricter details treatment, PHILLO brand PCC500-1 is supplied as Professional Type Cutter with diamond-edged blades 18~21 inches.
Parameters
Model | PCC500-1 |
Engine Model | Honda GX390/Loncin G420F |
Rated Power/Speed | 8.7Kw/11.7HP |
Fuel tank capacity | 6.1L/6.5L |
Work Revolution (r.min) | 3750 |
Blade Diameter (mm) | 450mm-500mm (18inch-20inch) |
Balde fitting hole Diameter (mm) | 25.4/50 |
Max cutting depth (mm) | 190 |
Depth Adjustment Mechanism | Handwheel rotation |
Water tank Capacity L | 40 |
Net weight(kgs) | 158 |
Gross weight（Kgs） | 180 |
Operating size mm(in) | 1270*638*1038 |
FEATURES
▶︎ Cutting depth 190mm at max;
▶︎ Cutting gauge;
▶︎ Gasoline engine Honda GX390( electric start/ recoil start,with oil sensor ) or economic engine Loncin G420F could be optioned;
▶︎ Equipped with an emergency stop switch;
▶︎ Handwheel rotation adjusts the cutting depth, with a depth indicator;
▶︎ Travel method: gear-driven mechanical feed;
▶︎ Water tank (40lits);
▶︎ Blade guard for operator protection;
▶︎ Single-point lifting hooks for easy loading and unloading.
